1.led tunnel light,tunnel light
2. Power:120w led tunnel light,
3.Power optional:120w,160w,200w
4.Die-casting aluminum casing and High intensity toughened glass cover
| Model Number | HM-LTL2*60W |
| LED Consumption | 109W |
| System Consumption | 125W |
| LED Initial Flux | WW | PW | CW |
| 8938 Lm | 9265 Lm | 9047 Lm |
| Light Body & Shade Material | Die-casting aluminum casing + toughened glass cover |
| Power Factor | >0.95 |
| Total Harmonic Distortion | <9% |
| Power Efficiency | >87% |
| Lighting Efficiency | >85% |
| Installation Height | (Height) 6M | (Height) 8M | (Height) 10M |
| Average Illuminance | >45.6 lux | >27 lux | >20 lux |
| Illuminance Area | 10 x 10 m | 14 x 14 m | 17 x 17 m |
| Illuminance Uniformity | >0.6 |
| Color Rendering Index | WW | | CW |
| Ra >68 | Ra >75 | Ra >75 |
| Beam Angle | 120° |
| Working Voltage | DC 30 ~ 36V |
| Input Voltage | AC 85 ~ 265V |
| Frequency | 50 ~ 60 Hz |
| LED Junction Temperature | ≤80ºC |
| Working Temperature | -40ºC~ +55ºC |
| IP Grade | IP 65 |
| LED Working Life-Span | >50000H |
| Certificate | CE , Rohs |
| Product Size | L600 x W280 x D120 mm |
| Net Weight / Gross Weight | 6.00 kg/ 6.50 kg |
Features:
1. Energy-saving with high efficency LED making, environment friendly and long lifespan upto 50000 hours;
2. Special reflector made from die cast aluminum for the best light diffusing;
3. Antisepticise closed silicone ring for light dustproof and waterproof;
4. Both AC and DC voltage are available;
5. Luminous flux ≥ 2 times of HPS.
Application:
Tunnel, Football field, Stage, Buildings, Advertising Board, Gym, Stadium, Yard, Lawn,Garden, Park, Plaza, Workshop,Warehouse, Shopping Mall, Exhibition Hall, Gas Station, Highway, Toll Station, Dock etc.
Notice:
1. Don't use in the place corrosive, flammable or explosive
2. Not install in the place near heat.
3. When the lamp lights, don't envisage it.
